| MODEL | ENGINE HP | PTO HP | LIFT CAPACITY | OPERATING WEIGHT | CYLINDER |
|---|---|---|---|---|---|
| 7030 4WD | 62 | 57 | 1800 | 2885 | 4 |
The NEF Series of engines offer an unmatched combination of performance fuel consumption and reliability. The high displacement coupled with advanced design ensures maximized torque levels as high as 238 Nm in 7030 4WD. And the excellent torque characteristics keep you moving even in the most difficult conditions.
The standard 8F+8R, fully synchromesh heavy duty transmissions are extremely reliable and easy to use. It incorporates wide range of gears to suit variety of applications and provides great strength for the high torque loads being transmitted. The left hand synchronized reverser provides smooth and great control for maximum productivity during intensive loader operations and headland operations.
The live powerful hydraulics boasts a maximum lift capacity of 1800 kg to handle the heaviest of implements. The lift rods and stabilizers are designed to allow easy implement hook up. Remote hydraulics control valves are provided as a standard feature to facilitate working with hydraulically powered implements.
Heavy & sturdy 3-point linkage is employed to ensure stability & safety.
High reliability in loader and field operations is ensured by using the front axle which is designed for heavier tractors. The Heavy Duty Front Axle with responsive hydrostatic steering provides a tight steering angle, so getting in & out of confined areas is easy. The 7030 4WD model employs ‘Limited Slip Differential’ which provides additional pulling power in tough soil conditions.
The low effort dual clutch is a simple, reliable unit designed for long lasting performance and smooth engagements.It features large diamete discs providing ample surface area to transfer power effectively. The seat designed for operator comfort features formed cushions. It is adjustable fore, alt and for height as well.All the control levers are ergonmically placed offering ease of operations
