Key features

ENGINE

Four Stroke, direct injection,

water cooled, Diesel engine

PTO TYPE

Single speed (opt. Dual

Speed)

PTO RPM

540, 540E

TRANSMISSION TYPE

Full Constantmesh

LIFT CAPACITY

2000

HYDRAULIC RESPONSE

ADVANCED

Models

MODELENGINE HPPTO HPLIFT CAPACITYOPERATING WEIGHTCYLINDER
505049.344.9200022004

Features

Advantages of the new generation technologically advanced engine

– 18% more back up torque: lesser drop in rpm and a powerful engine to ensure you remain unstoppable even on hard soil. – More power: now get the ability to work with bigger implements. – Lower specific fuel consumption: covers more ground while consuming lesser diesel, giving you even more savings. – Service interval of 400 hours: a longer service interval means one less servicing every year. – Dry type air cleaner: reduced time in cleaning the air cleaner means even more ease in maintenance. – Parallel cooling system: engine remains cooler for longer, so you can work longer.

Feature packed transmission

Full Constant mesh transmission comes with ergonomically placed shifting levers for fatigue free operations. The standard 12F + 12R speeds allows the tractor to work with any implement at required speed. Speed options ranging from 1.47 to 32.15 Kmph, helps optimise agri activities from ploughing to harvesting. The rear axle has large oil-immersed brakes for more brake efficiency & safety, Planetary drive for strength & reliability. The low effort dual clutch is a simple, reliable unit designed for long lasting performance and smooth engagements. Independent PTO Lever offer ease in engagement & disengagement during all PTO driven applications.

Powerful hydraulics and sturdy 3-point linkage.

The powerful Hydraulics boasts a high-tech control valve design along with its two bell crank arrangement, works with the right sensitivity on any type of soil and completes the task with precision. It has a lift capacity of 2000 kg to handle the heaviest of implements. It has a higher capacity pump flow which ensures easy operation in power steering & tipping trailer application. It has a side mounted control valve that can be removed without removing the Hydraulic during servicing. A sturdy 3 point linkage is employed to ensure stability & safety.

Heavy duty front axle

These tractors have heavy duty front axles for stability & control. Sufficient Axle (High Swing Angle) oscillation ensures a comfortable ride and allows the tractor to counter uneven terrain.

Comfortable work environment

Operator weight adjustable seat, ergonomically located pedals & controls are provided for fatigue free driving. The tractor boasts of bold wrap around clear lens headlamps, modern instrument cluster & attractive two-toned front grille.
