Key Features

ENGINE

FOUR STROKE, DIRECT INJECTION, WATER COOLED, DIESEL ENGINE 45-50

PTO TYPE

STANDARD

PTO RPM

540@1900 550@2100

TRANSMISSION TYPE

8 FORWARD 2 REVERSE FULL CONSTANTMESH

LIFT CAPACITY

1485 – 1650

HYDRAULIC RESPONSE

ADVANCED

Models

MODELENGINE HPPTO HPLIFT CAPACITYOPERATING WEIGHTCYLINDER
575 DI NST4540148520304
595 DI NST5044165020254

Features

THE POWERFUL, HIGH DISPLACEMENT, HIGH TORQUE ENGINE

These direct injection, three cylinder engines with a high displacement and rated at only 1900 rpm (2100 rated rpm in 595 DI), provide excellent torque characteristics, fuel efficiency and durability. The unique LLA technology employed in these engines optimally regulate the fuel injection according to changing load and rpm giving high fuel savings. The smooth running diesel engine with lower rated rpm means less wear and tear for longer engine life. The engine provides highest rated torque in its category, delivering an abundant supply of power while tilling with heavy implements or pulling loaded trailers up steep hills. These engines also produce cleaner emissions & conforms to BS lilA norms.

HEAVY DUTY FRONT AXLE:

Made of heavy-duty steel, the new design

HEAVY DUTY TRANSMISSION:

The heavy duty transmission with 8 forward and 2 reverse speeds is extremely easy to operate. Designed to match the impressive power and torque characteristics of the engine, the transmission incorporates very wide gears offering great strength. These transmissions are designed to be extremely efficient, with most of the engine HP available at the axles. This ensures that the tractor delivers high levels of Drawbar Power, higher productivity with minimal slippage making them ideal for draft applications such as deep puddling, cultivation and harrowing.

HIGH LIFT HYDRAULICS

The live powerful hydraulics boasts a maximum lift capacity as high as 1650 Kgs. in 595 DI to handle the heaviest of implements. These tractors employ heavy and sturdy 3-Point Linkage to ensure stability and safety. The standard draft control feature adds to the ease of operation when using ground engaging implements.

COMFORTABLE OPERATOR PLATFORM & CONTROLS:

The low effort diaphragm clutch is a simple, reliable unit designed for long lasting performance and smooth engagements. Dual clutch provided as an option, is available on 595 DI and offers a reverse live PTO. A fully enclosed & sealed housing with large sized multiple discs are used in brakes on either side, so that a large frictional area is available for efficient braking of these tractors, even while hauling large loads. These tractors are available with optional oil cooled brakes (wet discs brakes) which keeps the discs cool resulting in much longer disc life. These tractors with the long clutch housing offer a very wide passage that makes entry and exit very easy. All control levers are ergonomically placed and the hydraulics levers have been raised for an easy access. The uncluttered, comfortable S. roomy operator area facilitates long hours of driving.
