Key Features

ENGINE

Four Stroke, Direct Injection, Water Cooled, Diesel Engine (Turbocharged for 75 HP model)

PTO TYPE

Independent PTO

PTO RPM

540, 540E 540, 540E 540, 540E and Reverse

TRANSMISSION TYPE

15 Forward, 15 Reverse with Forward-Reverse shuttle

LIFT CAPACITY

2200 – 2600

HYDRAULIC RESPONSE

Advanced

Models

MODELENGINE HPPTO HPLIFT CAPACITYOPERATING WEIGHTCYLINDER
6060 4WD5750220031594
6065 4WD6557220033264
6065 2WD6254.5260031654
6065 4WD6254.5260033754
6075 2WD7364260031654
6075 4WD7364260033754
6075 4WD7566260034454

Features

NEW GENERATION, TECHNOLOGICALLY ADVANCED ENGINE

The 6000 Series tractors are powered by a naturally aspirated, 4 cylinder direct injection diesel engine. They are designed to ensure a flat torque curve and maximized torque levels, as high as 227 Nm for 6060 model, 260 Nm for 6065 model Si, 306Nm for 6075 model, ensuring maximum productivity in both PTO and draft applications. Excellent Torque reserve up to 20% [all models) gives plenty of lugging ability reducing the need for frequent gear shifts during tough conditions. The radiator, biggest in size, allows for efficient cooling of the engine.

HEAVY DUTY TRANSMISSION

The standard 15F+15R, partial synchromesh heavy duty transmissions are extremely reliable and easy to-use. They incorporate very wide gears providing great strength for the high torque loads being transmitted. The high nos of speed options allows to perform a broad range of farming applications successfully. The shuttle shift makes shifting between forward and reverse smooth and quick, thereby ensuring maximum productivity during intense loader and headland operations. It eliminates the need to depress the clutch every time you change directions, thereby ensuring maximum productivity during intensive headland operations. Independent PTO Lever offer ease in engagement Si. disengagement during all PTO driven applications.

POWERFUL HYDRAULICS AND STURDY 3-POINT LINKAGE.

Heavy and sturdy 3 point linkage is employed to ensure stability and safety. The telescopic lower links provide fast and simple attachment of rear mounted implements. The live powerful hydraulics boasts a maximum lift capacity of 2200 kg for 6060 model & 2600 kg for 6065 & 6075 models, to handle the heaviest of implements. Two double acting remote control valves are standard.

HEAVY DUTY FRONT AXLE

High reliability in loader and field operations is ensured by using the front axle which is designed for higher class tractors. In the 4WD models, the epicyclic reduction offers high dynamic load carrying capacity and is designed for maximum performance in loader and field operations. The responsive hydrostatic steering has a tight steering angle, for effortless maneuvering even in confined areas.

COMFORTABLE WORK ENVIRONMENT

The fully flat operator deck with side shift gear levers, suspended brake and clutch pedal provides lots of legroom and a spacious work area. The seat comes with various comfort features like formed cushions, adjustable suspension, just what you need for those long hauls
