| MODEL | ENGINE HP | PTO HP | LIFT CAPACITY | OPERATING WEIGHT | CYLINDER |
|---|---|---|---|---|---|
| 9200 4WD | 92 HP | 74 HP | 1800 KG. | 3155 KG. | 4 |
The turbocharged engines in these tractors offer an unmatched combination of performance, fuel efficiency and reliability. They are designed to ensure a flat torque curve and maximized torque levels as high as 276 Nm that ensures maximum productivity in both, PTO and draft applications.
The synchromesh transmission provides smooth shifting on the move. The standard 12F+12R speeds maximize performance with a choice of speeds. The dedicated left-hand synchronized reverser provides smooth control for maximum productivity during intensive loader and headland operations. The rear axle has large oil cooled disc brakes and heavy-duty inboard planetary reduction units for strength, safety and reliability.
The side-shift gear controls and suspended brake and clutch pedals provide added leg room and a roomy platform. The uncluttered operator platform makes for easy entry and exit.
The front axle with a ‘limited slip differential’ in the 4WD models provides additional pulling power in tough soil conditions. The planetary reduction offers high dynamic load carrying capacity and is designed for maximum performance in loader and field operations.
Sturdy 3-point linkage is employed with the lift rods and stabilizers designed to allow easy implement hook up. The tractor comes with a standard remote auxiliary valve to work with different hydraulic implements.
